| Material: | Carbon Steel | Property Class: | 6 |
|---|---|---|---|
| Hardness: | HRC 20 | Finish: | Zinc |
| Color: | Silver | Speicification: | M2 To M12 |
| High Light: | rivets and fasteners,small rivets |
||
M2 - M12 Carbon Steel Round Head Solid Rivets for Heavy Load DIN660
Round head solid rivets are made from carbon steel material with zinc finish , and widely used as structural pieces in aircraft and car industry .
Material
Solid rivet structure is very simple but quite useful with assorted specifications that can be made from aluminum ,alloy steel ,brass and stainless steel
Stainless steel : SUS 201 , SUS303 , SUS 304 ,SUS 316 , SUS 416 ,SUS 430 and SUS 420
Carbon steel : 1008 , 1010 , 1018 , 1022 , 1035 , 1045 , SCM 435 and 40CRO
Aluminum : 2024 , 6061 and 7075
Brass : CuZn35 , CuZn37 , CuZn40 , CuZn37Pb1 and CuZn39Pb1
Specifications
Generally , specifications for round solid rivets from 2 mm to 36 mm based on DIN or ISO standards .
unit : mm
| d | l | D | K |
| 2 | 3 ~ 16 | 4.5 | 1.2 |
| 3 | 5~ 26 | 5.5 | 1.6 |
| 4 | 7 ~ 50 | 7.0 | 2.5 |
| 5 | 7 ~ 55 | 8.7 | 2.8 |
| 6 | 8 ~ 60 | 11.0 | 3.5 |
| 8 | 15 ~ 65 | 14.0 | 4.8 |
| 10 | 15 ~ 85 | 17.0 | 6.0 |
| 12 | 20 ~ 90 | 21.0 | 8.0 |
| 14 | 22 ~ 100 | 24.2 | 9.0 |
| 16 | 26 ~ 110 | 29.0 | 10.0 |
| 18 | 32 ~ 150 | 32.0 | 12.0 |
| 20 | 32 ~ 150 | 35 | 14.0 |
| 22 | 38 ~ 180 | 38.0 | 15.0 |
| 24 | 52 ~ 180 | 43.0 | 17.0 |
| 27 | 55 ~ 180 | 48.0 | 19.0 |
| 30 | 55 ~ 180 | 53.0 | 21.0 |
| 36 | 58 ~ 200 | 62.0 | 25.0 |
We provide various finish with eco-friendly for round head solid rivets to meet your different demands .
| Finish | Colors | Thickness | Charicteristic |
| Zinc | Blue ,White ,Black ,Yellow | 5-107μm | Bright and smooth surface ,corrosion resistance |
| Nickel | Silver | 1～3μm | Wear resistance ,bright appearance , anti-corrosion |
| Polishing | Silver | 0.01mm ( reference ) | Improving brightness of surface |
| Tin | Silver | 0.13～1.27μm | Good ductility ,corrosion resistance ,lower melting point ,eco-friendly ,brightness |
| Brass | Copper | 5gm～8gm | Good dispersibility ,Bright appearance |
| Dacromet | Grey | 4-8μm | High corrosion resistance , No hydrogen embrittlement ,Heat resistance ,Easy to plated more ,eco-friendly |
| Chrome | Silver white | 0．25～0．5μm |
Harden surface ,Bright surface ,Heat resistance ,Wear resistance Corrosion resistance and eco-friendly |
Applications
Round head solid rivets are applied for various fields in industry as joint role
Installation tips
1 , Solid rivets are anti- disassembly once installed
2 , Make sure the pre-hole size is suitable for solid rivet
3 , Different materials and sizes for different proof load
