Product Details:
Payment & Shipping Terms:
|
| Material: | Spring Steel | Property Class: | 1065 |
|---|---|---|---|
| Hardness: | HRC45 | Finish: | Zinc |
| Color: | Black | Height: | 15 Mm |
| Width: | 11 Mm | Thickness: | 0.5 Mm |
| High Light: | stamping metal parts,metal stamping products |
||
Sheet Metal Stamping Parts 15mm Height Black Spring Steel V Shaped Brackets
Spring steel V bracket is stamped in sheet with holes for screw to secure parts and brackets after assembled , both holes are placed on each side and stand one a parallel line face to face so that screw can be gone from one hole to another hole . a hole in side is round but is a clip mouth in the hole for another side , this clip mouth provides fastening screw purpose .
Generally , V brackets are fit for self tapping screws with sharp point .
Material
V brackets are made of spring steel 1065 for good flexibility request .
Features
1 , Good elongation
Spring steel V bracket stamping parts are engouh flexible , they can back to old places even are deformed under pressure .
2 , High Tensile strength
The tensile strength for Spring Steel V brackets is up to 1050 Mpa .
3 , Strict Tolerance
Spring Steel V brackets are made in small toleranes +/-0.1 mm .
4 , Stable dimensions
Spring steel V brackets can be used many times and a tiny difference on sizes even have been served much times .
Physical Performance
| Tensile strength σb (MPa) | 1050 |
| Yield Strength σs (MPa) | 800 |
| Elongation δ 0.2 (%) | 21 |
| Reduction of area ψ (%) | 12 |
| Density g/cm3) | 7.81 |
Specification
| Height | 25 |
| Width | 10 |
| Thickness | 0.5 |
| Suitable screw | +/-0.1 |
| Color | Black |
| Finish | Zinc |
| Distance between sides | 11 |
Note : All are in millimeters
Spirng steel V bracket stamping parts
Finish
Spring steel V bracket stamping parts are plated in black zinc with thickness 5um . , besides , V bracket stamping parts are also available for following finish
Zinc
The most popular with bright and smooth and resistant corrosion , the finish thickness from 1 um to 25 um .
Nickel
The film thickness is 1～3μm , improves brightness and wear resistance
Tin
With film thickness 0.13～1.27μm , tin finish with bright surface and good ductility ,corrosion resistance ,lower melting point ,eco-friendly features .
Chrome
Chrome finish is silver white color and the thickness of film is 0．25～0．5μm normally . chrome finish has many practical Features like Bright appearance ,Wear resistance ,Corrosion resistance ,Hard plating film ,Heat resistance .
Packing
Spring steel V brackets are packed 500 pcs each bag , and 20 bags to a carton with chipboard . we accept customized packages.
Shipping Policy
Normal shipment is epxpress service for small order that quantiy is below 50 kgs , we can check the shipping cost for you if you are more like CFR or cIF trade terms .
We manage different brackets stamping parts in materials for wide industry application , please contact us if you need any help or need on stamping parts and other metal fastener .
